1.5 Ton Hydraulic Crawler Dump Truck

Irrigation Trenches: Creating irrigation trenches for agricultural purposes, especially in fields or smaller farming operations.
Field Maintenance: Digging channels for flood irrigation or clearing land for planting.

Contact Now Telephone WhatsApp

Product Details

Municipal Work:

1.5 Ton Hydraulic Crawler Dump Truck Sidewalk or Road Repairs: Used in cities for minor repairs or digging small trenches for utility work under roads or sidewalks.
Utility Repairs: Quick and efficient excavation of existing utility lines when repairs are necessary.

1.5 Ton Hydraulic Crawler Dump Truck

Packaging
Sticky Packing Size (Bucket Landing Position) (mm)	284010002200mm
Packing size (closed position) (mm)	235010002200mm
Wooden box size (mm)	285711401698
Packing	Wooden case

Product Information
Product net weight (kg)	880
Gross weight with wooden box (kg) Wooden box weight 125kg	1005
Operating weight (kg) (net weight + load)	1000
Maximum load (kg)	120
Color	Orange + Black
Maximum traveling speed (km/h)	2.5-3
Rated slewing speed (rpm)	11
Fuel tank capacity (L)	7
Hydraulic oil tank capacity (L)	14
Fuel consumption (L/h)	1.5L/h
Side Swing Angle	No function
Chassis telescopic function	No function
Awning way	Four-legged shed
Distribution position	Each cylinder oil pipe, each motor oil pipe
Number of steel wire layers	Double-layer steel wire
Peak pressure resistance value (Mpa)	≥40

Portability and Flexibility: The ability to transport the mini excavator using the truck increases the versatility of the equipment, making it easier to move between job sites, especially in areas with difficult access.

Engine
Engine Model	Bailiton Twin Cylinder 3864
Engine power (hp)	23hp
Rated speed (rpm)	3600
Engine type	Air-cooled four-stroke, OHV
Displacement (CC)	627
Engine Cylinder Form	V-twin, cast iron cylinder liner
Engine Bore (mm)	75.5
Engine Stroke (mm)	70
Engine oil capacity (L)	1.7
Engine net weight (kg)	35
Rated torque (N.m)	47.5@3060
Fuel type	Gasoline 90# and above
Oil type	10-30 (W)
Cooling type	Air-cooled
Emission standard	EPA

Compact Design: The 1.5-ton excavator can operate in tight spaces, such as small residential properties, narrow streets, and urban areas, which larger machines cannot access.

Control system
Controls	Hydraulic pilot type on both sides
Chronographs	Yes
Voltmeter	No
Battery Voltage (V)	12
Battery Capacity (AH)	45
Battery Size (mm)	238130200+20 (column height 20)
Battery Weight (kg)	12
Battery Positive Terminal Diameter (mm)	19
Battery Negative Terminal Diameter (mm)	17
Maximum starting current (A)	380

Main Pump
Main Pump Model	PGP51063GLP
Main pump type	Duplex Gear Pumps
Rated pressure of main pump (Mpa)	18
Maximum pressure of main pump (Mpa)	25
Nominal flow rate of main pump (ml/r)	6+3
Hydraulic oil type	46#Anti-wear hydraulic oil
Main pump flow rate (L/min)	27L/min@3000rpm
Brand	Customized model
Model	Customized model
Rated pressure of main pump (Mpa)	17.5

Fuel Efficiency: The combination of a small-sized excavator with a truck typically results in lower operational costs due to better fuel economy.

walking system
Model	BM6-310
Type	Cycloid Motor
Gear	First gear
Function of oil unloading	No
Track material	Rubber
Track width (mm)	180
Pitch of track (mm)	72
Number of track sections	37
Number of supporting wheels	2

Airframe Configuration
Roof form	Four-legged shed
Cabin heat insulation foam	Upper engine
Boom hydraulic pipe routing	Outer alignment
Boom cylinder mounting position	Lower side of big arm positively mounted
Fuel filling position	Under Seat
Hydraulic oil filling position	Footrest right side
Cabin door opening method	Upper side seat forward
Chassis hook	Chassis four hooks
Throttle valve	No throttle
Seat armrests	Without armrests
Seat belts	with
Anti-slip feet	with
Rubber skid cover for operating rod	Digging lever
Material of hydraulic pipe of big arm	Hose
Hydraulic Oil Heat Dissipation	Without hydraulic oil cooling
Engine cooling	Air Cooled

Convenience: Having the mini-excavator and truck combination ensures that you can bring everything needed for excavation, trenching, and small-scale projects without requiring additional logistics for transportation.

Adaptability of aids
Attachment link shaft diameter (mm)	25
Width of small arm end (mm)	90
Specification of reserved hydraulic connector	M16 male thread
Number of reserved hydraulic joints	2
Thumb Clamp Adaptation Form	Upper Single Hole Style
Outer width of mounting on the thumb clamp of small arm (mm)	47
Thumb clamp upper mounting hole opening distance (mm)	47
Small arm thumb clamp lower mounting hole width (mm)	90
Diameter of small arm thumb clamp hole (mm)	25.5

Vehicle Specifications
Maximum length (mm)	3750
Bulldozer width (mm)	1000
Overall width (mm) (both sides of chassis hook)	1060
Overall track width (mm)	1000
Overall height cab top (mm)	2250
Track distance (mm)	820
Track length to ground (mm)	885
Track Length (mm)	1230
Standard (single) track width (mm)	180
Swivel platform ground clearance (mm)	375
Traveling Minimum Ground Clearance (mm)	98
Minimum turning radius (mm)	1560
Standard bucket volume (m3)	0.025
Standard bucket width (mm)	400

Cost-Effective: Because of its small size and fuel-efficient design, a 1.5-ton crawler excavator paired with a transport truck is more affordable than larger machines, making it an excellent option for small construction firms, landscapers, and contractors working on tight budgets.

Working Size
Maximum digging force of bucket (KN)	14.5
Maximum load (kg)	120
Maximum digging depth (mm)	1795
Maximum vertical digging depth (mm)	1595
Maximum digging height (mm)	2325
Maximum unloading height (mm)	1505
Maximum digging radius (mm)	2900
Climbing capacity (°)	30
Maximum height of bulldozer (mm)	310
Maximum depth of bulldozer (mm)	270

A 1.5-ton crawler excavator truck setup is an excellent choice for contractors and construction professionals looking for a compact, portable, and efficient solution for small to medium excavation tasks. The combination of a small excavator and a transport truck provides flexibility, easy mobility, and the ability to work in confined spaces, making it ideal for residential, landscaping, utility, and small-scale municipal projects.
