Loader Mini Track Skid Steer
Construction:
Excavating, grading, and backfilling.
Loading trucks with gravel, soil, or other materials.
Breaking concrete and small structures with hydraulic hammers.
Diesel Engine:
Loader Mini Track Skid Steer and fuel-efficient, designed for heavy-duty work.
Horsepower Range:
Typically 20 to 50 HP, depending on the model.
Hydraulic Pressure:
Ensures sufficient power for lifting and operating hydraulic attachments.
Load and Lifting Capacity
Rated Operating Capacity (ROC):
Generally ranges from 500 to 1,500 lbs, depending on the machine size.
Item Name | 380 |
Working weight of the whole machine(kg) | 870 |
Bucket capacity(m³). | 0.12 |
Traveling speed(Km/h) | 3 |
Max. lifting force(Kg). | 220 |
Max. working height(mm). | 2235 |
Maximum unloading height(mm). | 1340 |
Bucket discharge angle | 25 |
Wheelbase H(mm) ::. | 780 |
Engine model | Brighton |
Maximum flow rate of spare fuel line(L/min) | 65 |
Horsepower hp | 23 |
Nominal speed rpm | 3600 |
Main pump type/model. | Gear pumps |
Maximum flow rate of main pump(L/min). | 65 |
Multi-way valve | 2-way + 3-way manual valves |
Traveling hydraulic motor type. | Cycloidal motors |
Motor displacement(ml) | 375 |
Rubber(bandwidth*pitch*number of sections). | 180*72*37 |
Tensioning type | Hydraulic tensioning |
Total length(mm) | 2250 |
Total width(mm). | 1100 |
Total Height(mm). | 1260 |
Lift Height:
Can lift materials to heights between 6 and 10 feet, depending on the model.
Operator Comfort
Ergonomic Controls:
Joystick operation ensures ease of use and precision.
Cab Options:
Open cabs for easy access or enclosed cabs with climate control for comfort in extreme weather.
Visibility:
Unobstructed view of the work area enhances safety and efficiency.
