Skid Steer Loader
Speed and Maneuverability:
High travel speed compared to tracked models, reducing operation time.
Ability to turn in place makes it suitable for tight spaces.
Operator Comfort and Safety:
Cab Design:
Open Cab: Skid Steer Loader lightweight and accessible for milder climates.
Enclosed Cab: Includes heating and air conditioning for all-weather operation.
Controls: Joystick or foot pedal operation for smooth and precise control.
Parameter table | Accessory brands | |
Item name | 430 | |
Working weight of the whole machine(kg) | 920 | |
Bucket capacity(m³). | 0.12 | |
Traveling speed(Km/h) | 3 | |
Max. lifting force(Kg). | 280 | |
Max. working height(mm). | 2235 | |
Maximum unloading height(mm). | 1340 | |
Bucket discharge angle | 25 | |
Wheelbase H(mm) | 780 | |
Engine model | Bristol-Myers Squibb | |
Maximum flow rate of spare fuel line(L/min) | 65 | |
Horsepower hp | 23 | |
Nominal speed rpm | 3600 | |
Main pump type/model | gear pumps | Tianjin Walking |
Maximum flow rate of main pump(L/min). | 65 | |
Multi-way valve | 2-way + 3-way manual valves | Huai'an Taiheng |
Traveling hydraulic motor type. | cycloid motor | Shandong Kern Hydraulics/Eaton |
Motor displacement(ml) | 375 | |
Rubber(bandwidth*pitch*number of sections). | 180*72*37 | |
Tensioning type | Hydraulic Tensioning | Crawler Original |
Total length(mm) | 2250 | |
Total width(mm). | 1100 | |
Total Height(mm). | 1260 | |
Visibility: Panoramic windows for better site awareness.
Construction:
Digging, backfilling, and leveling soil.
Transporting materials like gravel or concrete.
Loading dump trucks and moving debris.
Landscaping:
Grading and leveling land for gardens or patios.
Removing stumps, rocks, and debris.
Spreading mulch, soil, or gravel.
Agriculture:
Feeding livestock and cleaning barns.
Transporting hay bales and other farm materials.
Clearing land and digging irrigation channels.
Municipal and Roadwork:
Clearing snow and sweeping streets.
Digging trenches for utility lines.
Repairing sidewalks and small road sections.
Demolition:
Breaking down walls and small structures with hydraulic hammers.
Removing debris from demolition sites.
