Mini Skid Steer Loader

Clearing land, digging trenches for irrigation systems, and transporting materials.

Soil cultivation and preparation for planting.

Moving large loads like hay bales or feed.


Contact Now Telephone WhatsApp
Product Details

Mini Skid Steer Loader Landscaping:

    • Preparing grounds for gardens, lawns, or other landscaping features.

    • Mini Skid Steer Loader, removing stumps, or grading.

    • Sweeping or cleaning debris with specialized attachments.

    Mini Skid Steer Loader

      Municipal and Utility Work:

    • Laying utility lines or pipes.

    • Performing road maintenance or repairs.

    • Snow removal or clearing debris from streets or parks.

    Mini Skid Steer Loader

    Item Name

    380

    Working weight of the whole machine(kg)

    870

    Bucket capacity(m³).

    0.12

    Traveling speed(Km/h)

    3

    Max. lifting force(Kg).

    220

    Max. working height(mm).

    2235

    Maximum unloading height(mm).

    1340

    Bucket discharge angle

    25

    Wheelbase H(mm) ::.

    780

    Engine model

    Brighton

    Maximum flow rate of spare fuel line(L/min)

    65

    Horsepower hp

    23

    Nominal speed rpm

    3600

    Main pump type/model.

    Gear pumps

    Maximum flow rate of main pump(L/min).

    65

    Multi-way valve

    2-way + 3-way manual valves

    Traveling hydraulic motor type.

    Cycloidal motors

    Motor displacement(ml)

    375

    Rubber(bandwidth*pitch*number of sections).

    180*72*37

    Tensioning type

    Hydraulic tensioning

    Total length(mm)

    2250

    Total width(mm).

    1100

    Total Height(mm).

    1260

      • Forestry:

      • Transporting logs or materials.

      • Digging or trenching for forestry applications.

      • Clearing and leveling land for new projects.

        Superior Traction:

      • Tracks provide excellent stability on uneven or soft ground, making it possible to work in challenging conditions.

        Versatility:

      • Can work on various surfaces such as soft soil, rough terrain, and hard surfaces, making it suitable for many industries and applications.

        Powerful Performance:

      • Diesel engines offer strong power and torque for heavy-duty tasks, making it an ideal machine for demanding operations.


      Mini Skid Steer Loader

        • Low Ground Pressure:

        • The tracked design reduces ground pressure, allowing the machine to work in sensitive areas without causing damage.

          Increased Mobility:

        • Hybrid design with wheels provides better speed and efficiency on hard surfaces, while tracks offer stability on soft surfaces.

          Reduced Maintenance Costs:

        • Diesel engines generally have longer lifespans and require less frequent servicing, leading to cost savings.
