Track Mini Skid Steer Loader

While this machine often features tracks for improved ground traction, it also has wheels, which offer enhanced speed and mobility on hard surfaces. The hybrid design allows for seamless transitions between different terrains.The wheel-crawler hybrid system can switch between being tracked or wheeled, optimizing efficiency on different surfaces.

Contact Now Telephone WhatsApp

Product Details

Attachments:

Buckets: For Track Mini Skid Steer Loader digging, grading, and hauling.
Augers: For drilling holes or foundations.

Track Mini Skid Steer Loader

Hydraulic Hammers: For demolition and breaking concrete.
Forks: For lifting and transporting heavy loads.
Trenchers: For digging trenches in tight spaces.
Snow Plows: For clearing roads and pathways.

Track Mini Skid Steer Loader

Item Name	380
Working weight of the whole machine(kg)	870
Bucket capacity(m³).	0.12
Traveling speed(Km/h)	3
Max. lifting force(Kg).	220
Max. working height(mm).	2235
Maximum unloading height(mm).	1340
Bucket discharge angle	25
Wheelbase H(mm) ::.	780
Engine model	Brighton
Maximum flow rate of spare fuel line(L/min)	65
Horsepower hp	23
Nominal speed rpm	3600
Main pump type/model.	Gear pumps
Maximum flow rate of main pump(L/min).	65
Multi-way valve	2-way + 3-way manual valves
Traveling hydraulic motor type.	Cycloidal motors
Motor displacement(ml)	375
Rubber(bandwidthpitchnumber of sections).	1807237
Tensioning type	Hydraulic tensioning
Total length(mm)	2250
Total width(mm).	1100
Total Height(mm).	1260

Compatible with various attachments such as:

Quick Attach System:

Many models come with a quick-attach system, allowing operators to easily switch between attachments depending on the task at hand.

Track Mini Skid Steer Loader

5. Size and Weight

Compact Design:

The size and weight vary depending on the machine’s purpose and attachments but typically range from 1,500 to 4,000 kg (3,300 to 8,800 lbs).
Compact models are ideal for tight workspaces, offering better maneuverability in small areas.
