Mining Track Skid Steer Loader

The Mini Track Skid Steer Loader is a compact and versatile machine ideal for working in confined spaces and on soft or uneven terrain. Equipped with rubber or steel tracks, it offers superior traction and stability compared to wheeled models, making it highly effective for landscaping, construction, agriculture, and other applications.

Contact Now Telephone WhatsApp

Product Details

Size and Dimensions:

Compact Design: Mining Track Skid Steer Loader allows access to tight areas, including backyards and narrow pathways.
Weight: Typically ranges from 1,500 to 3,000 lbs, depending on the model.
Width: Generally 3 to 4.5 feet, suitable for narrow workspaces.

Mini Track Skid Steer Loader

2. Tracks and Mobility:

Rubber Tracks: Minimize surface damage and are ideal for delicate surfaces like lawns or finished landscapes.
Steel Tracks: Provide better durability and grip on rugged or abrasive surfaces.
Low Ground Pressure: Distributes weight evenly, reducing soil compaction and enabling work on soft, muddy, or sandy terrain.

Parameter table		Accessory brands
Item name	430
Working weight of the whole machine(kg)	920
Bucket capacity(m³).	0.12
Traveling speed(Km/h)	3
Max. lifting force(Kg).	280
Max. working height(mm).	2235
Maximum unloading height(mm).	1340
Bucket discharge angle	25
Wheelbase H(mm)	780
Engine model	Bristol-Myers Squibb
Maximum flow rate of spare fuel line(L/min)	65
Horsepower hp	23
Nominal speed rpm	3600
Main pump type/model	gear pumps	Tianjin Walking
Maximum flow rate of main pump(L/min).	65
Multi-way valve	2-way + 3-way manual valves	Huai'an Taiheng
Traveling hydraulic motor type.	cycloid motor	Shandong Kern Hydraulics/Eaton
Motor displacement(ml)	375
Rubber(bandwidthpitchnumber of sections).	1807237
Tensioning type	Hydraulic Tensioning	Crawler Original
Total length(mm)	2250
Total width(mm).	1100
Total Height(mm).	1260

3. Engine and Power:

Diesel Engine: Provides reliable power and efficiency.
Horsepower: Ranges from 20 to 40 HP for most mini track loaders, ensuring sufficient force for small to medium tasks.
Fuel Efficiency: Engineered for extended operation on a single tank.

4. Operating Capacity:

Rated Operating Capacity (ROC): Typically 500 to 1,500 lbs, depending on the model.
Bucket Capacity: Generally 0.1 to 0.3 cubic meters (0.1 to 0.4 cubic yards).
Lift Height: Ranges from 5 to 8 feet, making it suitable for loading trucks or small-scale material handling.

Mini Track Skid Steer Loader
